хм, и за ЭТО с людей дерут по $200… себестоимость все этого 282руб в ценах chip-and-dip

;------------------------------------------------------------------------------

; Hondainfo"s Speed Limit Defencer

; AT89C4051 mikrokontroller assembly program

; V1.2 2003.10.22

;------------------------------------------------------------------------------

$mod51
;------------------------------------------------------------------------------

; Theory:

;

; The VSS signal (measured data)

; At 60 km/h    Freq: 42 Hz

; At 100 km/h   Freq: 70 Hz

; At 120 km/h   Freq: 84 Hz

; At 170 km/h   Freq: 119 Hz

; duty in all case:50%

;

; This program is a simple signal copy when the frequency of signal is below 119 Hz

; Above 119Hz, the program switches to Virtual mode and sends Virtual

; 119 Hz signals to ECU independ on Input signal frequency.

;

;------------------------------------------------------------------------------

;------------------------------------------------------------------------------

; Memory variables:

;------------------------------------------------------------------------------

; pin definition

VSS_IN  EQU P3.7        ; Recieve VSS signal here

VSS_OUT EQU P1.7        ; artifical VSS signal to ECU (0: transistor is closed, 1: transistor is opened, pull the signal to Gr

VIRTUAL bit 001h        ; mode: =1 Virtual, =0 real signal output

VSS_OLD bit 002h        ; altering of sampled signal

COUNTR  data 030h       ; Real Counter counts the time beetween two VSS signal

COUNTV  data 031h       ; Virtual counter for artifical VSS signal output

;------------------------------------------------------------------------------

; Cнmdeffinition, interrupt table

;------------------------------------------------------------------------------

  RESET code 00000h

  org 0000h                                     ;starting here after Reset

    ljmp kezdet

  org 0003h

    reti

  org 000bh                                     ;Timer 0 interrupt

    ljmp T0_int

  org 0013h

    reti

  org 001bh

    reti

  org 0023h

    reti

  org 002bh

    reti

  org 30h

;------------------------------------------------------------------------------

;       22.1184 Mhz quartz

;       Timer 0 interrupt aprox: 0,0434 ms time base for measuring milisecs

;       - run 23040 times per a second

;       time period: 43 us

;       runing time max: 30 us

;------------------------------------------------------------------------------

T0_int:         PUSH PSW

                mov TL0,#0B0h           ; software reload

                mov TH0,#0FFh

                mov TCON,#050h

;*****MEASURING VSS SIGNAL

                jb VSS_IN,Ti0           ; jump if no signal (1->0 edge)

                jnb VSS_OLD,Ti0         ; jump if previous sample similar

                mov a,#192d             ; there is signal, check the counter

                clr c                   ; 192x0,0434ms=8,33msec (119 Hz)

                subb A,COUNTR

                cpl c                   ; If <= 8,33 msec then switch to virtual signal mode

                mov VIRTUAL,c           ; If > 8.33 msec then switch to Real signal mode

                mov COUNTR,#0ffh        ; Initial Real Counter

Ti0:            mov c,VSS_IN            ; sample altering

                mov VSS_OLD,c

                mov a,COUNTR

                xrl a,#250d             ; increment Real Counter, but max: 250

                jz Ti1

                inc COUNTR

;*****VIRTUAL COUNTER

Ti1:            mov a,COUNTV

                xrl a,#192d             ; increment Virtual Counter 0-192 cycle

                jnz Ti11

                mov COUNTV,#0ffh

Ti11:           inc COUNTV

;*****REAL MODE SIGNAL COPY

Ti2:            jb VIRTUAL,Ti3          ; jump if Virtual mode

                mov c,VSS_IN            ; In Real Mode simple SIGNAL COPY

                cpl c

                mov VSS_OUT,c

                sjmp Ti4

;*****VIRTUAL MODE ARTIFICAL SIGNAL OUTPUT

Ti3:            mov a,#096d             ; Virtual signaling above 170 kph

                clr c                   ; send 0 to output (pull to the ground)

                subb A,COUNTV           ; when Virtual Counter <=96

                cpl c                   ; send 1 to output (release)

                mov VSS_OUT,c           ; when Virtual Counter >96

Ti4:            POP PSW

                reti                    ; END OF INTERRUPT
;------------------------------------------------------------------------------

;Starting after Reset, int init

;------------------------------------------------------------------------------

kezdet:         clr VSS_OUT             ; init output

                mov c,VSS_IN            ; first altering

                mov VSS_OLD,c

                mov COUNTR,#250d

                mov COUNTV,#000d

                clr VIRTUAL

                mov TMOD,#021h          ; init timers T1 mode 2 (Auto Reload, Serial Port)

                mov TL1,#0FFH           ; T0 mode 1 (16 bit timer, software reload, Interrupt)

                mov TH1,#0FFH           ; serial port timing 9600 baud (use for testing)

                mov TL0,#0B0h           ; 65536d-80d-t to the counter init

                mov TH0,#0FFh           ;

                mov SCON,#052H          ; serial port mode 1

                mov TCON,#050h          ; Timer1 , Timer0 indul

                mov IE,#092h            ; RI/TI int enabled, T0 int enabled

ciklus:         sjmp ciklus
end
